LR03 product details Battery weight 11.3g Total battery height 43.8-44.3mm Battery diameter 10.10-10.30mm Battery open circuit voltage Initial value ≥1.610V Twelve months later ≥1.580V Battery short-circuit current Initial value ≥8A Twelve months later ≥6A

Battery discharge performance (initial period)

Discharge load Discharge mode Termination voltage Discharge time Battery capacity Sample measured value 3.9Ω 24h/d 0.9V ≥130min ≥600mAH 142min 5.1Ω 4m/h, 8h/d 0.9V ≥230min ≥700mAH 240min 10Ω 1h/d 0.9V ≥7.5h ≥900mAH 8.4h 24Ω 15s/m, 8h/d 1V ≥18.5h ≥950mAH 19.5h 75Ω 4h/d 0.9V ≥70h ≥1100mAH 71.5h 600mA 10s/m, 1h/d 0.9V ≥300次 ≥500mAH 330次

Note: The storage period of the battery shall be at least 12 months, and the discharge index of the battery during the storage period shall be 90% of the average discharge time in the initial period
Battery leakage resistance: ① 60 ℃, RH90%, no leakage after 20 days of storage ② 70 ℃, no leakage after 25 days of high temperature storage
Battery safety performance: ① Three charge and one test without explosion ② External short circuit test: no explosion
Battery storage period: It can be stored for three years at room temperature
